Discovery

Installation

Four securing holes. For recess or surface mounting on ceilings or walls. Brackets for recessed installation ordered separately, please see accessories. There are holes for a surface mounted installation socket.
The luminaire must not be covered with insulation. For further details please refer to the assembly instructions.

Connection

230 V integrated LED driver. Snap-in terminal block 5x2.5 mm². 1-phase through-wiring possible. Cable entry at rear or via knockouts for surface mounting, through wiring 0° or 180°.

Design

Luminaire body of polycarbonate and diffuser of opal polycarbonate.

Emergency lighting

Decentralised emergency lighting luminaire, 3 h, with self-test AT4 and the possibility to connect a monitoring system based on communication via DALI. The system is not dependent on a DALI system being connected or in operation. Emergency lighting luminaires can be supplemented with sensor on request.

Dimming

e-Sense BrightSwitch – PIR sensors with lux threshold. Presence control on/off. Absence dimming high/low available on request.
e-Sense Detect – Microwave sensors with lux threshold. Presence control on/off via relay or high/low, alternatively high/low/off via DALI.
e-Sense Flex – Integrated sensors with ambient light sensor. Presence/absense control high/low/off. Wireless communication via Bluetooth mesh. Suffix -569 equipped with microwave sensor.
Organic Response – PIR sensor with presence and daylight control. All luminaires act as master/slave with IR communication.

Accessories

Anti-ligature casing in white enamelled aluminium. Supplied with safety screws (tamper-proof torx) IK10, IP 55. Outdoor casing in lacquered aluminium, IK10, IP 55 with the possibility of a surface mounted mains cable.

Miscellaneous

CLO (Constant Light Output) means that the luminaire provides the same amount of light for the duration of its specified burn-time.
