Multilume Hydro Robust G3
101916 Multilume Hydro G3 101916
Recessed or surface mounted with Delta louvre and impact-resistant PETG in various sizes for demanding environments. IP 44 under a suspended ceiling and IP 20 above a suspended ceiling.
Installation
Recessed or surface mounted. The recessed model is suitable for fixed suspended ceilings or suspended ceilings with visible T-bars.
Connection
Connected to 2.5 mm² 3-way terminal block 3x1.5 mm² (x2), with the possibility of through-wiring. 5x1.5 mm² (x2) when dimming. Can also be supplied with mains cable and earthed plug or chassis mounted snap-in connector. The luminaire housing and driver are connected via a Quick Connection System. The surface mounted model has cable entries fitted with blanking grommets on the back.
Design
Luminaire body in extruded aluminium and enamelled sheet steel. Surface mounted model in white enamelled sheet steel (RAL 9016).
Louvre
Delta – microprismatic acrylic louvre (PMMA) with 4mm impact resistant PETG.
Dimming
Luminaires with DALI/phase pulse control have CLO (Constant Light Output) as standard. Luminaires with Tunable White (2700-6500 K) are equipped with DALI device Type 8 driver.
Miscellaneous
CLO (Constant Light Output) maintains the correct light from the luminaire for the duration of its rated life.
Multilume Hydro G3
Multilume Hydro G3 is a product family of extremely energy-efficient luminaires – with good light comfort – for demanding environments.
The luminaire is dust and damp proof according to IP 65 below suspended ceilings, or IP 20...
More about the family Multilume Hydro G3Other products
Document
Customise with Fagerhult Configure
Adapt and optimise the luminaire in Fagerhult’s configurator. You can easily select the CRI, colour temperature, optics, luminous flux, controls, various connection options, and more. All your selections are saved to a product data sheet which you can download along with unique light data files.
- Adapt and optimise the luminaire
- Download unique data sheet and light data files
- To order, contact your sales representative
